MK115-wireless smart plug wifi EU 16A electric socket power monitor remote control smart plug
1.Introduction

MK115 is a smart home device using Wi-Fi connection wireless technology that turns your typical electrical device into a smart, controllable, and multifunctional device. And it has a small, compact enclosure, also easy for installation.
The plug can be operated using the button on the casing or via mobile APP through WIFI. It works as a smart energy meter with extremely high accuracy and mainly used in household appliance control and industrial equipment control so as to monitor the power and energy consumption and save energy.

2.Feature

Built-in ESP32 module and MOKO standard firmware
Remote control appliance power ON/OFF on APP
Measures active power consumption and energy consumption with ±0.5% accuracy
Detects if electrical load is connected to it
Overload protection
Indicates state and consumption using multiple-color LED ring
Firmware update over the air (OTA)
Supports multiple MQTT servers to connect to Cloud server or local server
Supports Android & IOS APP SDK for APP developing
Power metering SDK and schematic diagrams are available for customers to develop firmware
Supports customized hardware with Zigbee, Z-wave, BLE and other wireless type
EU directives compliance: RED 2014/53/EU
3.Application Scene

Smart home household appliance control
Industrial electrical devices control
Energy management
4. Basic Parameters

NO. Type Description
1 Wireless technology WIFI
2 Input voltage 230VAC
3 Output voltage 230VAC
4 Max load current 11A,continuous load
5 Max load 2530W,continuous load
6 Operation temperature 0 ºC~ 40 ºC ( 32°F ~ 104°F )
7 Plug type Type E/F
8 EU directives compliance RED 2014/53/EU
